• Rear axle, 4.56 ratio
• Transfer case, 4.03:1 2-speed, button-actuated full-time 4WD
• Differential, driver-selectable cast-iron full-locking front
• Differential, driver-selectable full-locking rear
• Four wheel drive
• Battery, heavy-duty 590 cold-cranking amps, maintenance-free with rundown protection
• Alternator, 125 amps
• Recovery hooks, 2 front and 1 rear
• Skid Plate Package includes skid plates for front and steering/suspension, transfer case and fuel tank
• GVWR, 6001 lbs. (2722 kg)
• Reactor system air-injection, electric
• Suspension, front, independent, heavy-duty with torsion bar
• Suspension, rear semi-floating axle with 2-stage multi-leaf springs
• Steering, power, rack-and-pinion
• Brakes, 4-wheel antilock, 4-wheel disc with a unique calibration for 4Lo

• Wheels, 5 - 16" x 7.5" (40.6 cm x 19.1 cm) steel, painted Smoke Gray (May be upgraded to (QA7) 4- 16" x 7.5" (40.6 cm x 19.1 cm) aluminum wheels or (QB9) 4 - 16" x 7.5" polished aluminum wheels if (PCX) Appearance Packed is ordered.)
• Tires, LT285/75R16 on-/off-road, blackwall
• Tire, full-size spare with painted steel wheel, under-body-mounted
• Luggage rack side rails, roof-mounted
• Bumpers, front and rear steel (not jackable)
• Grille, chrome 7-slot
• Headlamps, dual composite halogen with automatic exterior lamp control
• Fog lamps, front, halogen
• Mirrors, outside power-adjustable, manual-folding
• Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield, driver- and front passenger-side glass)
• Wipers, front intermittent, variable, wiper/washer
• Body, endgate
• Rail caps, pickup box bed
• Bedliner

• Audio system, AM/FM stereo with 6-disc in-dash CD changer, seek-and-scan, digital clock, auto-tone control, speed-compensated volume and TheftLock. Includes (UQA) Monsoon performance-enhanced premium 6-speaker system (May be substituted with (UM8) AM/FM stereo with CD and DVD-integrated navigation.)
• Audio system feature, Monsoon performance-enhanced premium 6-speaker system with amplifier and rear subwoofer
• XM Radio is standard on more than 50 2010 GM models, including three trial months of service. XM turns your world on with commercial-free music channels for virtually every music genre, all in amazing digital quality sound. Turn your favorite sports, the biggest names in News, Talk and Comedy, family programming, exclusive concerts and original music series, wherever you go from coast to coast. Everything worth listening to is no on XM (XM service available only in the 48 contiguous United States and the District of Columbia. XM Radio subscription required and sold separately after trial period. Fees, taxes, and a one-time reactivation fee, may apply. Subscriptions goverened by XM Customer Agreement available at xmradio.com. All fees and programming subject to change. Family programming Packages are available.)
• Bluetooth® for phone personal cell phone connectivity to vehicle audio system and HMI (Human Machine Interface) (Requires (UE1) OnStar.)

• Seats, front bucket includes driver manual lumbar controls, adjustable outboard head restraints and map pockets on seatbacks
• Base Decor includes (**J) Cloth seat and cloth interior trim
• Seats, cloth
• Seats, front driver and passenger manual, lumbar only
• Seats, rear 60/40 split-folding
• Console, floor includes removable tray
• Floor covering, Ebony carpet
• Floor mats, ebony carpeted front, no accents
• Floor mats, ebony carpeted rear seat, no accents
• Steering wheel, vinyl
• Windows, power with driver Express-Down
• Retained accessory power
• Door locks, power
• Remote Keyless Entry with 2 transmitters and remote panic button
• Cruise control, electronic with set and resume speed
• Theft-deterrent system, vehicle, PASSlock II
• Air conditioning, single-zone manual
• Defogger, rear-window
• Glovebox, passenger-side
• Owners publication (Retail orders only)
• Cupholders, 2 front and 3 rear
• Power outlets, 2 auxiliary, 12-volt
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Visors, driver and front passenger includes vanity mirror on passenger side
• Assist handles, 5 total 1 A-pillar mounted for front passenger, 2 B-pillar and 2 overhead-mounted for outboard rear seats
• Lighting, interior with front and interior dome, reading, instrument panel courtesy, door switches and illuminated entry

• StabiliTrak, stability control system with Traction control and Hill Start Assist feature
• Traction control system
• Daytime Running Lamps
• Air bags, frontal, driver and right-front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your child's age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicle's Owner's Manual and child safety seat instructions for more safety information.)
• Air bags, head curtain side-impact, front and rear outboard seating positions with rollover sensor (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• OnStar, 1-year of Safe and Sound plan. Includes Automatic Crash Response, Emergency Services, Crisis Assist, Stolen Vehicle Assistance, Remote Door Unlock, Roadside Assistance, Remote Horn and Lights, Hands Free Calling, OnStar Vehicle Diagnostics, and Low Mileage Discount (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. Vehicle Diagnostics capabilities vary by model. Remote door unlock success varies with conditions. Ability to locate stolen vehicles varies with conditions. Subscription Service Agreement required. Call 1-888-4ONSTAR (1-888-466-7827) or visit onstar.com for OnStar's Terms and Conditions, Privacy Policy and details and system limitations.)
• Tire Pressure Monitor (Does not monitor spare.)
• Horn, single-note

Additional Packages

• Paint
• Solid

• LICENSE PLATE PROVISION FRONT (will be forced on orders with ship-to states that require a front license plate)
• LPO BLACK TUBULAR ASSIST STEPS frame-mounted textured step-pads with 3-inch stainless steel tubular design
• AUDIO SYSTEM AM/FM STEREO with 6-disc in-dash CD changer seek-and-scan digital clock auto-tone control speed-compensated volume and TheftLock. Includes (UQA) Monsoon performance-enhanced premium 6-speaker system (STD)
• TRAILERING EQUIPMENT includes trailer hitch and wiring harness
• ENGINE 3.7L DOHC 5-CYLINDER MFI (239 hp [178.2 kW] @ 5800 rpm 241 lb-ft of torque [325.3 N-m] @ 4600 rpm) (Not SAE certified.) (STD)
• SEATS FRONT BUCKET includes driver manual lumbar controls adjustable outboard head restraints and map pockets on seatbacks (STD)
• REAR AXLE 4.56 RATIO (STD)
• EBONY CLOTH SEAT TRIM
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive includes leather-wrapped shift handle must specify
• SEAT ADJUSTER DRIVER 8-WAY POWER with power lumbar control
• ADVENTURE PREFERRED EQUIPMENT GROUP includes Standard Equipment
• PAINT SOLID
• WHEELS 5 - 16" X 7.5" (40.6 CM X 19.1 CM) STEEL PAINTED SMOKE GRAY (STD)
• BIRCH WHITE
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tires - Front On/Off Road
• Tires - Rear On/Off Road
• Locking/Limited Slip Differential
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Steel Wheels
• Tires - Front On/Off Road
• Tires - Rear On/Off Road
• Conventional Spare Tire
• Automatic Headlights
• Fog Lamps
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Variable Speed Intermittent Wipers
• Bed Liner
• AM/FM Stereo
• CD Changer
• CD Player
• Premium Sound System
• Premium Sound System
• Satellite Radio
• Requires Subscription
• Bluetooth® Connection
• Bucket Seats
• Driver Adjustable Lumbar
• Cloth Seats
• Cloth Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Floor Mats
• Floor Mats
• Power Windows
• Power Door Locks
• Keyless Entry
• Power Door Locks
• Cruise Control
• Immobilizer
• A/C
• Rear Defrost
• Power Outlet
• Auto-Dimming Rearview Mirror
• Passenger Vanity Mirror
• Front Reading Lamps
• Traction Control
• Stability Control
• Traction Control
• Adjustable Steering Wheel
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag
• Telematics
• Requires Subscription
• Tire Pressure Monitor

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Pwr
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.4 x 1.1
• Rear Brake Rotor Diam x Thickness (in): 12.3 x 0.5
• Cargo Area Dimensions
• Cargo Area Length : Floor to Console (in)
• Cargo Area Length : Floor to Seat 1 (in)
• Cargo Area Length : Floor to Seat 2 (in)
• Cargo Area Length : Floor to Seat 3 (in)
• Cargo Area Length : Floor to Seat 4 (in)
• Cargo Area Width : Beltline (in)
• Cargo Box (Area) Height (in): 19.4
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume to Seat 1 (ft³): 33.5
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 125
• Emissions
• EPA Greenhouse Gas Score: 3
• Tons/yr of CO2 Emissions : 15K mi/year
• Exterior Dimensions
• Ground Clearance, Front (in): 9.5
• Ground Clearance, Rear (in): 9.5
• Height, Overall (in): 72.1
• Length, Overall w/rear bumper (in): 212.7
• Wheelbase (in): 134.2
• Width, Max w/o mirrors (in): 75.0
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 27
• Interior Dimensions
• Front Head Room (in): 40.7
• Front Hip Room (in): 53.9
• Front Leg Room (in): 41.9
• Front Shoulder Room (in): 54.4
• Passenger Capacity: 5
• Second Head Room (in): 39.5
• Second Hip Room (in): 52.6
• Second Leg Room (in): 34.2
• Second Shoulder Room (in): 54.0
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 18
• Fuel Economy Est-Combined (MPG): 16
• Steering
• Steering Ratio (:1), On Center: 16.0
• Steering Type: Pwr rack and pinion
• Turning Diameter - Curb to Curb (ft): 43.8
• Summary
• Body Code: 134.2" WB
• Body Style: 4 Door SUV
• Vehicle Name: HUMMER H3T
• Suspension
• Axle Capacity - Front (lbs): 3050
• Axle Capacity - Rear (lbs): 3250
• Axle Ratio (:1) - Front: 4.56
• Axle Ratio (:1) - Rear: 4.56
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 46
• Spring Capacity - Front (lbs): 3050
• Spring Capacity - Rear (lbs): 3200
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): 0.98
• Suspension Type - Front: Independent
• Suspension Type - Rear: Semi-floating
• Tires
• Front Tire Capacity (lbs): 2130
• Front Tire Order Code: QLB
• Front Tire Size: LT285/75R16
• Rear Tire Capacity (lbs): 2130
• Rear Tire Order Code: QLB
• Rear Tire Size: LT285/75R16
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 440
• Dead Weight Hitch - Max Trailer Wt. (lbs): 4400
• Weight Information
• Curb Weight - Front (lbs): 2467
• Curb Weight - Rear (lbs): 2467
• Gross Axle Wt Rating - Front (lbs): 3050
• Gross Axle Wt Rating - Rear (lbs): 3200
• Gross Vehicle Weight Rating Cap (lbs): 6001
• Wheels
• Front Wheel Material: Aluminum
• Front Wheel Size (in): 16 x 7.5
• Rear Wheel Material: Aluminum
• Rear Wheel Size (in): 16 x 7.5
• Spare Wheel Material: Aluminum
• Spare Wheel Size (in): 16 x 7.5
